NEW QUESTION 1
Scenario: A Citrix Administrator is configuring SNMP management on the NetScaler to receive alerts when something fails. The administrator was confident that the Manager, Alarms and SNMP Traps were configured correctly. The following week, there was a NetScaler-related outage and the administrator did NOT get any alerts.
What could be the reason for the SNMP alert failure?

• A. The Community Name was NOT configured on the NetScaler SNMP Trap Destination settings.
• B. The NetScaler only has Standard licensing.
• C. The NetScaler is configured for SNMP version 1.
• D. The NetScaler Application Firewall is blocking the alerts from going out.

Answer: A

NEW QUESTION 2
Scenario: A Citrix Administrator manages an environment that has three SSL websites, all serving the same content.
www.company.com www.company.net
www.company.org
The administrator would like to consolidate the website into a single, load-balanced SSL virtual server.
Which action can the administrator take to use a single SSL virtual server?

• A. Bind the certificate of each website to a single SSL virtual server.
• B. Bind a multiple Subject Alternative Name (SAN) certificate to a single SSL virtual server.
• C. Bind a Wildcard certificate to a single SSL virtual server.
• D. Bind a Wildcard certificate to a Content Switching virtual server.

Answer: D

NEW QUESTION 3
Which three statements are true when comparing a Simple Access Control List (ACL) to an Extended ACL? (Choose three.)

• A. Simple ACLs can be modified.
• B. Extended ACLs have priorities.
• C. Simple ACLs apply first.
• D. Extended ACLs apply first.
• E. Simple ACLs are based on the Source IP address only.
• F. Simple ACLs can bridge traffic.
• G. Simple ACLs can be based on the Source and Destination IP address.

Answer: BCE

NEW QUESTION 4
Scenario: A Citrix Administrator needs to add 10 new web servers to an existing server farm. The new servers are configured to serve the same applications and connections and are twice the capacity of the existing servers. The administrator wants to ensure that they are being fully utilized. Currently in the environment, the default load-balancing method is being used.
To ensure that only the 10 new servers are receiving twice the connections of the old servers without changing the load balancing to the rest of the environment, the administrator needs to add a weight of _____ to the services attached to the _____ servers. (Choose the correct option to complete the sentence.)

• A. 50; new
• B. 50; old
• C. 2; new
• D. 2; old

Answer: C

NEW QUESTION 5
Scenario: A Citrix Administrator manages an environment that has multiple websites running through a NetScaler MPX 5550. The NetScaler meets the needs of the environment throughout the year, except in December, when the capacity doubles. The administrator needs to handle this increased web traffic with a temporary, cost-effective solution.
Which action should the administrator recommend in order to handle the increased web traffic?

• A. Purchase a license to upgrade the MPX 5550 to a MPX 5650.
• B. Purchase a BurstPack License.
• C. Purchase Universal License.
• D. Purchase NetScaler Gateway Platform License.

Answer: B

NEW QUESTION 6
Scenario: A Citrix Administrator is managing a NetScaler SDX running eight NetScaler instances. The administrator first needs to upgrade the firmware on the instances. However, the administrator is concerned that it needs to be done all at once.
What upgrading flexibility does SDX provide in this scenario?

• A. The NetScaler instance can be upgraded at the SDX management level, allowing all instances to be upgraded at once.
• B. It is NOT possible to upgrade the NetScaler instances to different firmware versions.
• C. The NetScaler instance can be upgraded on an individual basis, allowing all instances to run different firmware versions.
• D. The NetScaler instances have to be upgraded at the same time.

Answer: D

NEW QUESTION 7
Scenario: A Citrix Administrator is executing the following commands on the NetScaler:
add policy dataset Admin_group ipv4
bind policy dataset Admin_group 192.168.149.10 –index 11 bind policy dataset Admin_group 192.168.149.39 –index 12 bind policy dataset Admin_group 192.168.149.49 –index 13 add responder policy POL_1
“!(CLIENT.IP.SRC.TYPECAST_TEXT_T.CONTAINS_ANY(”Admin_group”))” RESET
bind lb vserver ln_vsrv_www –policyName POL_1 –priority 100 –gotoPriorityExpression END –type REQUEST
What will be the effect of these commands?

• A. All the traffic from users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be blocked through the NetScaler.
• B. Only the users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be allowed to connect to vserver lb_vsrv_www.
• C. Only the users with a source IP address of 192.168.149.10, 192.168.149.39, or 192.168.149.49 will be blocked when attempting to connect to vserver lb_vsrv_www.
• D. Only the users with a source IP address of 192.168.149.10 or 192.168.149.39 will be allowed to connect to the virtual server.

Answer: B

NEW QUESTION 8
Scenario: A Citrix Administrator created an SSL virtual server using only the following commands:
add lb vserver sslvserver SSL 10.102.29.133 444 add service sslsvc1 192.168.0.14 SSL 443
add service sslsvc2 192.168.0.15 SSL 443 bind lb vserver sslvserver sslsvc1
bind lb vserver sslvserver sslsvc2
set ssl vserver sslvserver –ssl3 disabled
The SSL virtual server is currently in a DOWN state.
What could be the reason the SSL virtual server is in a down state?

• A. SSLv3 is disabled.
• B. The SSL Certificate is NOT bound to the virtual server.
• C. The SSL services are NOT on the 10.102.29.X network
• D. The virtual server SSL port is NOT set to port 443.

Answer: C

NEW QUESTION 9
View the Exhibit.

A Citrix Administrator has noticed that the users trying to access https://mycitrix.training.lab/exchange2021/owa are redirected to CAS_vserver_www instead of CAS_vserver_owa.
Click on the ‘Exhibit’ button to view the screenshot of the command-line interface. What should the administrator change to resolve this issue?

• A. Unbind cs vserver CAS_vserver_cs –lbvserver CAS_vserver_www
• B. Bind cs vserver CAS_vserver_cs –policyName CAS_policy_cs_owa –priority 120
• C. Bind cs vserver CAS_vserver_cs –policyName CAS_policy_cs_owa –priority 80
• D. Add cs policy CAS_policy_cs_owa –rule “HTTP.REQ.URL.SET_TEXT_MODE(IGNORECASE).CONTAINS(”/owa”)” –actionCAS_action_cs_owa

Answer: A

NEW QUESTION 10
View the Exhibit.

A Citrix Administrator has configured the commands using the command-line interface. Click on the ‘Exhibit’ button to view the screenshots of the command-line interface. What will be the effect of the rewrite policy, based on the exhibit?

• A. HTTP Header “SSL_parameter: icauser@mylab.lab” will be inserted in every RESPONSE.
• B. HTTP Header “SSL_parameter: icauser@mylab.lab” will be inserted in every REQUEST.
• C. HTTP Header “SSL_parameter: C=IN, ST=KA, O=Mylab, CN=icauser@mylab.lab” will be inserted in every RESPONSE.
• D. HTTP Header “SSL_parameter: C=IN, ST=KA, O=Mylab, CN=icauser@mylab.lab” will be inserted in every REQUEST.

Answer: A

NEW QUESTION 11
A Citrix Administrator needs to configure a rate limiting policy for the DNS requests to a threshold of 1000 DNS requests per second.
Which set of commands does the administrator need to run to correctly configure the rate limiting policy?

• A. add stream selector DNSSelector1 client.udp.dns.domainadd ns limitIdentifier DNSLimitIdentifier1 –threshold 5 –timeSlice 1000 –selectorName DNSSelector1add dns policy DNSLimitPolicy1 “sys.check_limit(”DNSLimitIdentifier1”)” –preferredLocation “North America.US.TX.Dallas..”bind dns global DNSLimitPolicy1 5
• B. add stream selector DNSSelector1 client.udp.dns.domainadd ns limitIdentifier DNSLimitIdentifier1 –threshold 5 –timeSlice 1000 –selectorName DNSSelector1add dns policy DNSLimitPolicy1 “sys.check_limit(”DNSLimitIdentifier1”)” –preferredLocation “North America.US.TX.Dallas..”
• C. add stream selector DNSSelector1 client.udp.dns.domainadd ns limitIdentifier DNSLimitIdentifier1 –threshold 1000 –timeSlice 1000 –selectorName DNSSelector1add dns policy DNSLimitPolicy1 “sys.check_limit(”DNSLimitIdentifier1”)” –preferredLocation “North America.US.TX.Dallas..”
• D. add stream selector DNSSelector1 client.udp.dns.domainadd ns limitIdentifier DNSLimitIdentifier1 –threshold 1000 –timeSlice 1000 –selectorName DNSSelector1add dns policy DNSLimitPolicy1 “sys.check_limit(”DNSLimitIdentifier1”)” –preferredLocation “North America.US.TX.Dallas..”bind dns global DNSLimitPolicy1 5

Answer: C

NEW QUESTION 12
A Citrix Administrator is configuring Unified Gateway with authentication policies. Where should the administrator configure NetScaler Gateway authentication policies?

• A. Global level
• B. Unified Gateway level
• C. Content-Switching level
• D. NetScaler Gateway level

Answer: D

NEW QUESTION 13
Scenario: A NetScaler appliance is having intermittent issues. A Citrix Administrator is unable to identify the root cause and fix them. The administrator opened a Support ticket and the Engineer assigned to the case requested all the logs and configuration information from the NetScaler.
Which technical support tool can the administrator use to gather all the information on the NetScaler to send to the Support Engineer?

• A. Batch Configuration
• B. Start New Trace
• C. Get Back Trace
• D. Generate Support File

Answer: C

NEW QUESTION 14
What are two advantages of using Content Switching for Global Server Load Balancing (GSLB) service selection? (Choose two.)

• A. Apply different load balancing methods on the different subsets of GSLB services in the deployment.
• B. Define a subset of GSLB services with different priorities and specify an order in which the services in the subset are applied to a request.
• C. Ability to bind multiple GSLB vServers with different protocol types under one Content Switching vServer.
• D. Bind multiple GSLB domains or FQDNs to a single GSLB vServer.

Answer: CD

NEW QUESTION 15
Scenario: A Citrix Administrator used the commands in the screenshot to apply the user- agent check to all the virtual servers. However, the administrator observed that it is NOT being applied to the vServer lb_vsrv_www.
Click on the ‘Exhibit’ button to view the screenshot of the command-line interface.

What can be causing this issue?

• A. Pattern set is being used with global policies.
• B. Logging action is bound to the Responder policy.
• C. The bind type of the policy drop is Default Global.
• D. Two responder policies are bound to same vServer.

Answer: D

NEW QUESTION 16
How does the NetScaler communicate that IP-to-MAC address bindings have changed to the switches and routers on the network, when a NetScaler high availability (HA) pair failover occurs?

• A. The NetScaler uses Gratuitous ARPs (GARPs) to update the devices on the network.
• B. The NetScaler uses MAC-based Forwarding to update the routers.
• C. The NetScaler uses Proxy ARP to update the devices on the network.
• D. The NetScaler uses Reverse ARP (RARP) to update the devices on the network.

Answer: B

NEW QUESTION 17
Scenario: A Citrix Administrator observes that when the client gets redirected to the URL www.citrix.com/owa/search?q-userbame, an HTTP 503 response is received from the Content Switching vServer.
The relevant configuration is as follows:

How will the administrator correct the issue?

• A. Unbind CS_POL_2
• B. Unbind CS_POL_1
• C. Bind Policy Unbind CS_POL_2 with priority 90
• D. Bind Policy Unbind CS_POL_3 with priority 90

Answer: C

NEW QUESTION 18
A Citrix Administrator needs to configure the Lights Out Management (LOM) port. Which statement is applicable to LOM?

• A. LOM is accessed using Command-Line Interface (CLI).
• B. LOM IP address should be in the same subnet as NSIP.
• C. LOM firmware is included in the NetScaler upgrade package.
• D. LOM port can be used to remotely monitor and manage the appliance.

Answer: A
