NEW QUESTION 1
You have a Cisco Nexus device that is configured to use RADIUS serve. What occur when local RBAC user account roles and RADIUS roles exist simultaneously?

• A. Only rules that are in the local roles and the RADIUS roles are applied
• B. Only rules from the local roles are applied.
• C. Only rules from the RADIUS roles are applied.
• D. The rules from the local roles and the RADIUS roles are merged.

Answer: B

NEW QUESTION 2
Refer to the Exhibits.

The blade server has two HBAs. How many WWPN targets on VSAN 2001 are accessible to the blade server?

• A. 1
• B. 2
• C. 3
• D. 4

Answer: D

NEW QUESTION 3
Refer to the exhibit :

You define the port profiles as shown in the exhibit, and then you assign the P10GIG port profile to interface el" Which option is the result of this configuration?

• A. The speed of the interface is 10 Gbps
• B. The speed of the interface is 1 Gbps
• C. The interface uses the maximum speed available for the physical interface.
• D. The speed of the interface is 100 GbpS

Answer: A

NEW QUESTION 4
You deploy AVS for Virtual Manager integration and you add a host that has five VMNICs. You must use VXLAN to maximize the load balancing of the traffic inside the fabric. How many VMKNICs must you add?

• A. 2
• B. 3
• C. 4
• D. 8

Answer: C

NEW QUESTION 5
Which two options are purposes of a device package? (Choose two )

• A. to identify a set of network or service functions required by the application
• B. to provide a leaf and spine devices with operating systems and firmware
• C. to provide a Cisco APIC with information about device specifics
• D. to render the services required by a graph
• E. to manage a class of service devices

Answer: CE

NEW QUESTION 6
When connecting to an external Layer 3 network, which two dynamic routing protocols can be used? (Choose two )

• A. RIPv2
• B. EIGRP
• C. VXLAN
• D. lS-IS
• E. OSPF

Answer: AB

NEW QUESTION 7
You have a new Cisco Nexus 7000 Series Switch that has only the default VDC configured .Which option describes the default behavior of the physical interfaces on the switch?

• A. The physical ports are divided into eight groups and the first group is assigned to the default VDC
• B. AJI of the physical ports on the switch are assigned to the default VDC
• C. None of the physical ports on the switch are assigned
• D. The physical ports are divided into six groups and the first group is assigned to the default VDC

Answer: C

NEW QUESTION 8
Which tool can you use to convert XML/JSON REST code to Python code?

• A. Postman
• B. Cobra
• C. Arya
• D. API Inspector

Answer: B

NEW QUESTION 9
When configuring port profiles on a Cisco Nexus 5000 Series switch, which two statements are true? (Choose two.)

• A. If a conflict occurs when a range of interfaces inherits a second port profile, the commands of the initial port profile override the commands of the second port profile.
• B. If a conflict occurs, commands that you enter the interface mod take precedence over profile commands.
• C. When an interface has a port profile applied to it, no other conflicting configuration can be applied to that interface.
• D. If a conflict occurs when a range of interface inherits a second port profile, the commands of the second ort profile override the commands of the initial port profile.
• E. If a conflict occurs, port profile takes precedence over commands that you enter under the interface mode.

Answer: BD

NEW QUESTION 10
You configure a Cisco Nexus device running in ACI mode to use a remote RADIUS server Which description of this configuration is true?

• A. If RADIUS authentication fails, the user is dented access without any additional authentication checks.
• B. If the RADIUS server is unreachable, the device falls back to the local authentication automatically
• C. If the RADIUS server is unreachable, users who have been authenticated recently can log m
• D. If RADIUS authentication fails, the device falls back to the local authentication automatically

Answer: D

NEW QUESTION 11
You are troubleshooting node discovery issues by using the acidiag fnvread command. Which description of the node status when the CLI output shows a status of Discovering is true?

• A. The node is decommissioned
• B. The node ID is configured, but not discovered yet
• C. The node is discovered, but an IP address is not assigned yet
• D. The node is discovered, but the node ID policy is not configured yet

Answer: C

NEW QUESTION 12
Which two components are essential parts of a Cisco ACI VMM domain policy? (Choose two.)

• A. VLAN pool association
• B. vSphere data center association
• C. attachable entity profile association
• D. IP address pool association
• E. Layer 3 outside interface association

Answer: AC

NEW QUESTION 13
Which situation causes POAP to auto provision a switch?

• A. The startup configuration is corrupt.
• B. The switch is powered on after being offline for more than 48 hours.
• C. The startup configuration is missing.The startup configuration is corrupt, and you manually rebooted the switch

Answer: C

NEW QUESTION 14
Which type of connection is supported by Layer 3 in the Cisco ACI fabric?

• A. eBGP over OSPF
• B. eBGP over EIGRP
• C. eBGP over RIP
• D. iBGP over EIGRP

Answer: A

NEW QUESTION 15
Which statement about POAP licensing correctly describes temporary licensing?

• A. Temporary licensing is invoked by using the license grace-period command
• B. Temporary licensing is enabled automatically and is valid for 60 days
• C. Temporary licensing is invoked by using the license Install command
• D. Temporary licensing is enabled automatically and is valid for 30 days

Answer: A

NEW QUESTION 16
Which two options are advantages of VMware AVS instead of a VMware vDS? (Choose two )

• A. AVS supports vPath
• B. AVS supports VLAN
• C. AVS provides a single point of management for networking
• D. AVS supports VXLAN
• E. AVS supports micro segmentation

Answer: BD

NEW QUESTION 17
Refer to the exhibit.

You attempt to configure a local SPAN session on a Cisco Nexus 1000V Series Switch by using the vEthernet interface of VM1 as the source port and the vEthernet destination port.
Which description of what happens to the SPAN session is true?

• A. It can be successfully only logged to a file on VEM1.
• B. It secceeds.
• C. Both VMs must be on same VLAN for this work.
• D. It fails.

Answer: D
