NEW QUESTION 1
You are troubleshooting media issues during SIP calls on AC-series collaboration endpoint that is running TC6.3 software. You are asked to recreate the problem and to provide a packet capture from the endpoint. Which four of the following are required to accurately perform a packet capture on AC-series endpoint? (Choose four.)

• A. Stop the capture by pressing the key combination Ctrl + C.
• B. Set up administrator access on the endpoint.
• C. Start the capture by entering the tcpdump command string and then start the call.
• D. Set up root access on the endpoint.
• E. Start the call, and then enter the tcpdump command string to begin the capture.
• F. On the endpoint, set the default transport to TLS.
• G. Set the default transport to TCP.

Answer: ACDG

NEW QUESTION 2
Refer to the exhibit.

An engineer configured CCD between a Cisco Unified Communications Manager (CUCM) cluster and Cisco Unified Communications Manager Express (CME). When the CUCM agents try to dial ACME extension on the range 7XXX, they receive ABusy signal as soon as the 7 is dialed. What can be done to resolve this issue?

• A. Set the CUCM CCD Requesting Service PSTN prefix to 9 instead of+
• B. Set the CME profile dn-block type to extension instead of global
• C. Set the CUCM Hosted DN Pattern PSTN Failover Strip Digits field to 1 instead of 0
• D. Set the CME subscribe callcontrol to instance instead of wildcarded

Answer: A

NEW QUESTION 3
What is the default directory format that you need to specify for Default TFTP MOH File Path field on the Cisco Unified Communications Manager (CUCM) server?

• A. MoH
• B. TFTPPATHMoH
• C. TFTPPATH
• D. MoHTFTPPATH
• E. TFTPPATHMoHFiles
• F. MoHFiles

Answer: C

NEW QUESTION 4
The link from your local Cisco Unity Connection site to another site has gone down. While troubleshooting, you discover that the local gateway is unable to reach a DNS server. Which action can you take to reestablish the link?

• A. Restart the Connection Manager series on the local gateway
• B. Create an intersite link manually using the IP address of the remote gateway.
• C. Synchronize the two Cisco Unity Connection sites.
• D. Create an intersite link manually using the FQDN of the remote gateway.
• E. Configure the directory synchronization task schedule on the remote gateway.

Answer: A

NEW QUESTION 5
Refer to the exhibit.

An engineer recently configured a Cisco Unified Communications Manager cluster. The
users are reporting that extensions starting with 10 are routing to a different office. Based on the output, what is the root cause of the issue?

• A. The destination partition is missing from the assigned calling search space
• B. Urgent priority is chosen on a translation or route pattern
• C. The incorrect calling search space was assigned to the phones
• D. The extension is a shared line, and one of the phones is unregistered

Answer: A

NEW QUESTION 6
After an IP Phone gets IP address information from DHCP, what is the next step in the initialization process?

• A. CTL and ITL files are downloaded.
• B. The phone requests its VLAN information.
• C. The DHCP offer is sent from the phone
• D. The TFTP server is contacted for configuration information.
• E. Nothing else is required, the phone is operational at this stage

Answer: D

NEW QUESTION 7
You have an endpoint registration problem with VCS, and the event log reason of “unknown domain”. The domain names that your endpoints are using to register with must be added to this list. Where do you check the list of defined domains?

• A. VCS configuration > Domains > SIP
• B. VCS configuration > Protocols > SCCP > Domains
• C. VCS Domains > Protocols > SIP
• D. VCS configuration > Protocols > SIP > Domains

Answer: D

Explanation: Reference: https://www.cisco.com/c/en/us/td/docs/telepresence/infrastructure/articles/ vcs_endpoint_registration_problems_kb_460.html

NEW QUESTION 8
You are configuring the Call Control Discovery feature. You need to configure Hosted DN Group Configuration settings. What is the range of values that you can define in the PSTN Failover Strip Digits field?

• A. 0-10
• B. 0-12
• C. 0-14
• D. 0-16
• E. 0-18
• F. 0-20

Answer: D

NEW QUESTION 9
After a Cisco Unified Communications Manager system is installed, users report problems when more than four users attempt to join a Meet-Me conference. Which parameter should you increase?

• A. Maximum Ad Hoc Conference, Call Manager Service Parameter
• B. Maximum Ad Hoc Conference, Enterprise Parameters Configuration
• C. Maximum Meet-Me Conference, Call Manager Service Parameter
• D. Maximum Meet-Me Conference, Enterprise Parameters Configuration

Answer: C

NEW QUESTION 10
Which three statements about SAF forwarding are true? (Choose three.)

• A. It supports DNS and IP addresses.
• B. The SAF Forwarder configuration can be updated without connecting to Cisco Unified Communications Manager.
• C. It requires the SAF Forwarders to use the same configuration as the IOS switch.
• D. It is supported on IPv4 only.
• E. It is supported on IPv6 only.
• F. It requires a unique IP address for each SAF Forwarder.

Answer: ABF

NEW QUESTION 11
Refer to the exhibit.

An IP phone that is connected through a Cisco Catalyst 3750 Series Switch is failing to register with Cisco Unified Communications Manager. When the user presses the settings button on the phone, the Operational VLAN ID shows ABlank entry. What is the most likely cause for this issue?

• A. The switch may not be supplying inline power.
• B. The spanning tree portfast command needs to be removed.
• C. The trunk encapsulation is missin
• D. The trunk must be configureDFor dot1.Q.
• E. Cisco Discovery Protocol is disabled on the switch.
• F. The Operational VLAN ID of the phone always shows as blan
• G. The Admi
• H. VLAN ID should be 110.

Answer: D

NEW QUESTION 12
Which three items are displayed on the endpoint registration verification page in Cisco VCS? (Choose three.)

• A. E.164 address
• B. endpoint name
• C. endpoint MAC address
• D. endpoint registration status
• E. device description
• F. device type
• G. device pool

Answer: ABF

NEW QUESTION 13
Which two statements about Cisco Unified CM location bandwidth deduction are true? (Choose two.)

• A. If a Call uses G.711, Cisco Unified Communications Manager subtracts 64k.
• B. If a Call uses G.711, Cisco Unified Communications Manager subtracts 80k.
• C. If a Call uses G.723, Cisco Unified Communications Manager subtracts 16k.
• D. If a Call uses G.729, Cisco Unified Communications Manager subtracts 16k.
• E. If a Call uses G.729, Cisco Unified Communications Manager subtracts 24k.

Answer: BE

NEW QUESTION 14
What does the debug output show? Refer to the exhibit.

• A. a DSP farm profile shutdown
• B. a DSP farm profile registration failure due to a TCP connection error
• C. a DSP farm profile registration failure Message due to a mismatched name
• D. that SCCP is not activated

Answer: C

NEW QUESTION 15
Which four performance counters are available when monitoring a Cisco MTP device using the Cisco Unified Communications Manager RTMT? (Choose four.)

• A. Resource Total
• B. Resource Available
• C. Out of Resources
• D. Resource Idle
• E. Resource Active
• F. MTP Streams Active
• G. MTP Connection Lost
• H. MTP Instances Active

Answer: ABCE

NEW QUESTION 16
While you deploy SAF CCD in a remote location, you are unable to enable the SAF CCD service on an Cisco IOS-based device. Which action can you take to troubleshoot the problem?

• A. Verify that Cisco Unity Express is operational.
• B. Verify that IOS Release 15.0(1)M is installed.
• C. Verify that DSP Farm resources are configured on the device.
• D. Verify that the device has sufficient RAM to run SAF CCD.
• E. Verify the integrity of the flash installation.

Answer: A

NEW QUESTION 17
Joe is based out of California, USA. He is travelling to London,U.K. for a few days. The ACME Corporation recently deployed Cisco Unified Communications Manager Device Mobility, and both the USA phone (Voice Subnet 10.1.1.0/24) and the London phone (Voice Subnet 10.2.2.0/24) are registered to the same Cisco Unified Communications Manager cluster. The publisher and two subscribers are in California, and the London site has two subscribers. When Joe connects his Cisco IP phone to the London network, the phone displays the message “Device in Home Location.” Assume that call routing, CSS, and partitions are set up in accordance with the country-specific dial plan. Which statement is true?

• A. To call a U.
• B. mobile phone, Joe must dial 9 (access code) + 011(international access code in the U.S.)+ 44 22 33 44 55 (U.
• C. dial plan)
• D. Joe is unable to call internal Cisco IP phones in the London office (assuming that CSS and partitions allow the call)
• E. Joe’s Cisco IP phone does not support roaming.
• F. In the UK, the international access code is 00. To call a U.
• G. number, Joe must dial 9 (access code) + 00+1 222 333 4567 (U.
• H. dial plan)

Answer: A

NEW QUESTION 18
Some of yours users report issues when they are dialing extensions located in other branch offices. Sometimes the calls are set up successfully, and sometimes users experience problems during call setup. Which two reasons for the issue are true? (Choose two)

• A. Not enough bandwidth is available between the two locations and Automated Alternate Routing is disabled on this cluster.
• B. The Partition that contains the calleDExtensions is not assigned to the line or device CSS of the calling users.
• C. A firewall rule blocks traffic between the branch offices so the call setup cannot be completed.
• D. The calleDExtension is used only on a device profile for extension mobility and the user has been authenticated to a second phone in a different branch so the calls are delivered randomly to only one of his phones.
• E. The remote branch experiences WAN link outages and there is no Forward Unregistered Internal number configureDFor the remote directory number.

Answer: AE

NEW QUESTION 19
What is the default interval for SAF hello packets?

• A. 15 seconds
• B. 15 seconds on links with speeds that are slower than T1 speeds
• C. 40 seconds
• D. 40 seconds on links with speeds that are slower than T1 speeds
• E. 60 seconds
• F. 60 seconds on links with speeds that are slower than T1 speeds

Answer: F

NEW QUESTION 20
Replication fails in a large Cisco Unified Communications Manager cluster that contains eight nodes. There are no issues with reachability between cluster nodes, and the utils dbreplication runtimestate command shows “out of sync” or “not requested” statuses. Which reason that is occurring is true?

• A. The replication timeout is too small
• B. Authentication failed on at least one of the nodes
• C. The clock of the Publisher is not synchronized
• D. The tables on one or more nodes are mismatched

Answer: A
