NEW QUESTION 1
Refer to the exhibit.

When adding an ASAv to the APIC, the user notices a fault raised on the device. Which cause of this fault is the most likely?

• A. The device package was never uploaded
• B. The incorrect username and password was used
• C. The configuration specified HTTP and not HTTPS
• D. The configuration did not specify “apic” as the username

Answer: D

NEW QUESTION 2
How do you manually configure a vNIC MAC address?

• A. Use the mac -address-table static command.
• B. Modify the dynamic vNIC connection policy.
• C. Use the set identity dynamic-mac command.
• D. Modify the adapter policy.

Answer: D

NEW QUESTION 3
Cisco UCS Director provides a facilitate acquisition of API information and help with API code generation. Which option accesses this feature?

• A. Enable the Developer tools in your web browser
• B. Download the ucsd-rest-api-sdk-x.x.0.0.zip file from the cisco.com software download area or the DevNet site
• C. Access the REST API browser in the cisco UCS Director GUI.
• D. Retrieve the list of acailable services using/app/api/restformattype=json&opName=userAPIGetAllServices&opData=0

Answer: C

NEW QUESTION 4
Which two connectivity modes does Cisco RISE support? (Choose 2)

• A. Directly connecte
• B. No virtual port channel is supported.
• C. Indirectly connecte
• D. Only Layer 3 adjacent.
• E. Indirectly connecte
• F. Only Layer 2 adjacent
• G. Indirectly connecte
• H. Layer 2 and Layer 3 adjacent.
• I. Directly connecte
• J. Virtual port channel is supported.

Answer: CE

NEW QUESTION 5
Which configuration step is needed is Cisco UCS Director to enable an option to metadata reportand
REST API Browser for developers?

• A. Enable the debugging menu
• B. Enable the REST API
• C. Enable the developer menu
• D. Enable report metadata

Answer: C

NEW QUESTION 6
When you add a VMM domain to an EPG in ACI, it seems that the host that is connected to the EPG- port group cannot communicate with its default gateway that configured on the EPG.
Which reason for this behavior is true?

• A. The VLAN to which the EPG belongs is not configured on the uplink from the fabric interconnect to the Cisco UCS
• B. The VLAN is blocked in the fabric interconnect.
• C. A contract blocks the communication from the host to its default gateway
• D. The configuration is not committed

Answer: A

NEW QUESTION 7
Which two statements about import and export route control in an ACI fabric are true? (Choose two.)

• A. Prefixes learned from OSPF/EIGRP L30urs are never permitted inbound by default.
• B. Prefixes learned from BGP L3outs cannot be filtered inbound.
• C. Export route control controls if the prefixes are redistributed from MP-BGP to the egress leaf.
• D. Prefixes permitted inbound are redistributed into MP-BGP at the ingress leaf.

Answer: CD

NEW QUESTION 8
Which two guidelines and limitations of netflow on Cisco NX-OS are true? (Choose two)

• A. If you change a layer 2 interface to a layer 3 interface, the software converts the layer 2 netflow to layer 3 netflow automatically.
• B. It is optional to configure a valid record name
• C. The cisco nexus 2000 series fabric extender does not support bridged netflow.
• D. Only layer 2 netflow is applied on layer 2 interfaces, and only layer 3 netflow is applied on layer 3 interfaces.
• E. You must configure a source interfac
• F. If you do not configure a source interface, the exported remains in a disabled state.

Answer: DE

NEW QUESTION 9
What is the correct upgrade sequence for Cisco Cloud Center components?

• A. CCM, AMQP, CCO, Health Monitor
• B. CCM, CCO, Health Monitor, AMQP
• C. CCM, CCO, AMQP Health Monitor
• D. CCM, Health Monitor, AMQP, CCO

Answer: C

NEW QUESTION 10
Which three statements are true about redistribution of routes from L3Outs in an ACI Fabric?
(Choose 3)

• A. Routes are not redistributed to leaf switches where the same VRF is present
• B. ACI fabric runs MP-BGP
• C. Security import subnets control the forwarding of packets into and out of L3Out connections(data plane)
• D. Routes learned from L3Outs on border leaf switches are not redistributed into MP-BGP at the ingress lead.
• E. Route control subnets control the exchange of routing information (Prefixes) into and out of the fabric (control place)
• F. The routes are advertised to all external Layer 3 Outside connections

Answer: BCE

NEW QUESTION 11
You are integrating Layer 4 - Layer 7 devices in a Cisco Application Centric Infrastructure deployment. Which option allows you to define a preset of policies to deploy when applying a service graph template?

• A. application profile
• B. service groups
• C. function profile
• D. policy groups

Answer: C

NEW QUESTION 12
Which multicast destination MAC address is assigned to LACP?

• A. 01:80:c2:00:00:02
• B. 01:80:c2:00:00:01
• C. 01:80:c2:00:00:03
• D. 01:80:c2:00:00:04

Answer: A

NEW QUESTION 13
Which two statements about attachable access entity profiles in the ACI Fabric are true? (Choose two)

• A. Enabling the infrastructure VLAN on an AEP is a mandatory requirement when the AEP is associated to any VMM domain
• B. AEP provides the association of a virtual machine management domain and the physical network infrastructure
• C. AEPs are an optional component to ACI access port configuration that ease the burdenof configuring multiple individual policies
• D. The attached entity profiles a template to deploy hypervisor policies on a large set of leaf ports
• E. AEPs are directly bound to spine and leaf Switch profiles and are then associated indirectly to interface selectors

Answer: AB

Explanation: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/1-x/basic-config/b_ACI_Config_Guide/b_ACI_Config_Guide_chapter_0101.html#concept_C3EF1E36E8F6406A 96A71E605AC175BD

NEW QUESTION 14
Which of the following statements regarding Multi-Pod deployment is true?

• A. Each Pod is assigned a separate and not overlapping TEP pool
• B. TEP pools are used for layer 2 communication between the Pods
• C. Each Pod selects its own TEP pool as its locally significant
• D. TEP pool are not redistributed to the leaf nodes as they are only limited to spines

Answer: A

Explanation: https://www.cisco.com/c/en/us/solutions/collateral/data-center-virtualization/application-centric-infrastructure/white-paper-c11-737855.html

NEW QUESTION 15
Which two descriptions of the Cisco 7000 RISE Technology are true? (Choose two.)

• A. RISE enables remote inspection of control plane traffic to address security concerns.
• B. RISE can provide ADC offload freeing resources in the ADC.
• C. RISE enables remote inspection of data plane traffic to address security concerns
• D. RISE enables a physical appliance to appear as a service module in the Cisco Nexis 7000 chassis
• E. RISE can be utilized to provide management capabilities for non-Cisco routers.

Answer: DE

NEW QUESTION 16
Refer to exhibit.

Which two statements about this command are true? (Choose two)

• A. The command is usually used FCIP over the overlay
• B. The command is used to extend the spanning tree for VLAN 72 across the overlay
• C. The command is used to enable unknown unicast flooding for a known MAC address across the overlay
• D. The command is used in HSRP localization for OTV
• E. The command is usually used for Microsoft network load balancing implementation

Answer: CE

NEW QUESTION 17
Which two statements about the Cisco Fibre Channel Domain feature and persistent FC IDs are true? (Choose two.)

• A. A persistent FC ID that is assigned to an F Port cannot be moved across interfaces if the same persistent FC ID is to be maintained.
• B. When persistent FC IDs are enabled, FC IDs cannot be changed after a reboot.
• C. If you connect to the switch from a Windows host, be sure to enable the persistent FC ID feature in the VSAN that connects these hosts.
• D. The current FC IDs in use in the fcdomain are saved across reboots.
• E. Entries that the switch has learned must be manually acknowledged to be stored in the FCDomain FCID database.

Answer: BD

NEW QUESTION 18
Which definition of Intelligent Service Card Manager is true?

• A. part of the RISE service that resides on an appliance (for example, Citrix NetScaler) that is responsible for sending Route Health Injection messages to a Cisco Nexus switch
• B. management software to manage provisioning of RISE services on a Cisco Nexusswitch
• C. management software to manage Cisco Nexus devices
• D. part of the RISE service that resides on a Cisco Nexus switch that is responsible for handlingtasks related to receiving Route Health Injection messages from appliances and programmingthose routes in the universal routing information base
• E. part of the RISE service that is responsible for establishing initial connectivity with remoteappliances (for exampl
• F. Citrix NetScaler)

Answer: D

NEW QUESTION 19
What is the correct location where the DPDK libraries run?

• A. User space
• B. Network Space
• C. Kernel Space
• D. Disk Space

Answer: A
